1926 Chrysler Imperial E-80 Specifications and Equipment

Imperial Home Page -> Imperials by Year -> 1926 -> Specifications

Serial numbers for the E-80 were ED000W to EW66655S.  Engine numbers are located in the same place as body numbers.

STANDARD EQUIPMENT

ENGINE

Inline, L- head Six

Cast Iron Block

Bore & Stroke : 3.5 inches x 5 inches

Displacement : 288 cubic inches

Cranking Rate : 4.7:1

Brake Horsepower : 92@3000

N.A.C.C. Horsepower : 29.4

Seven Main Bearings

Solid Valve Lifters

Carburetor - Ball & Ball



CHASSIS

Wheelbase : 127 inches

Special order wheelbase: 133 inches

Tires : 32 x 6.25



TRANSMISSION

Manual transmission.  Speeds: 3R/1R.  Multi-disc clutch.  Shaft drive.



FOUR-WHEEL HYDRAULIC BRAKES





WOODEN SPOKE WHEELS





OPTIONS

Double bar front bumpers

Double bar rear guards

Wind wings

Step plates

Trunk rack

Spare tire

Sidemount spares

Accessory radiator cap

Touring trunks

Wide sidewall tires

Side curtains

OSRV mirrors

Pedestal mirrors for sidemounts

Special paint

Wire spoke wheels

IMPERIAL CUSTOM BODIES
